WordQ User Guide

Getting Started

About WordQ PDF

WordQ PDF is an application within WordQ that allows you to open PDF documents (local, cloud or web) for accessible* reading and writing. In addition to general reading of a PDF document, it is perfect for completing assignments and tests that are provided as PDFs. You can fill in form fields or add your own text boxes; add sticky notes; and mark up text with annotations. All of these can be edited at any time.

All WordQ functions are available to work with a PDF document including:

  • Word prediction with dynamic topics to assist typing into a PDF document: fillable form fields, user-added text boxes, sticky notes, and annotations
  • Reading back typed text, and reading aloud with word-by-word highlighting of both editable and non-editable text
  • WordQ proofreading strategy
  • *Documents that have been scanned must be converted first by OCR

    Toolbar

    Hide Left Navigation Panel     Hide Left Navigation Panel hides the left Navigation panel if it is shown

    Left Navigation Panel     Show Left Navigation Panel displays all pages as thumbnails; displays an outline or table of contents of the document if it is included; allows searching for a word or phrase in the document; and lists all annotations, highlights, marked text, and added drawing objects

    Open File     Open... displays a File Open dialog to choose a PDF document

    Save     Save a PDF document

    Print     Print... a PDF document

    Pan     Pan lets you scroll through a PDF document and some other features described in next section

    Select Text     Select Text lets you select non-editable text to read

    Select Annotation     Edit Annotation lets you modify notes and drawn objects

    Text Box     Text Box creates a box for you to type

    Sticky Note     Sticky Note creates a sticky note to add an annotation

    Fit Page     Fit Page fits the page within the height of the window

    Fit Width     Fit Width fits the page across the width of the window

    Single Page     Single Page displays a single page at a time

    Facing Pages     Facing displays pages side-by-side

    Rotate Clockwise     Rotate Clockwise rotates the page clockwise

    Rotate Counterclockwise     Rotate Counterclockwise rotates the page counterclockwise

    Open a PDF

    Open a PDF document from your local or cloud drive:

    1. Select Open PDF... from WordQ's Option Menu to open the WordQ PDF application (if not already running).

    2. An Open dialog will be displayed. Choose the PDF document from your local or cloud drive.

    3. The Pan Pan button will be initially selected. In Pan mode, you can:
      • Pan or scroll through the document
      • Fill in text form fields with full WordQ support (e.g., word prediction, speech feedback
      • Select check boxes and choice buttons in a form
      • Position the cursor over any annotation for that annotation to appear and be read automatically.
        Move the cursor away to hide the annotation

    Open a PDF document from the web:

    1. Click Cancel to close the File Open dialog.

    2. In a browser, locate the desired PDF document.

    3. Save the document to your local or cloud drive.
      This is necessary as you will not have permission to write over the web document online.

    4. Click on the Open... Open File button or choose File>Open... to open the saved PDF document. Then follow the steps described above.
    Read non-editable text
    1. Click the Select Text Select Text button.

    2. Using your mouse or touchpad (or other pointing device), drag over the text to be read, then click the Read button in WordQ or use its hotkey.

    3. Use the SPACEBAR to pause/play reading with word-by-word highlighting.

    4. After pausing, you may:
      • Read individual words by pressing RIGHT or LEFT arrow keys to move within a sentence
      • Continue reading by pressing SPACEBAR
      • Go to the previous or next sentence by pressing UP or DOWN arrow keys

    Adding/Editing Text and Comments

    Add a text box
    1. Click the Text Box Free Text button.

    2. Position the cursor where you want to type and drag to create a text box (that you can move or resize later).

    3. Type in the text box with full WordQ support.

    4. When you finish typing, click anywhere else in the document and you will revert to Pan Panmode.
    Add a Sticky Note
    1. Click the Sticky Note Note button.

    2. Click in the document where you wish to add your note. A pop-up note box will be displayed for typing your note.

    3. Type in the note box with full WordQ support.

    4. Within any note, the following standard shortcut keys are available to apply to your text:

      • CTRL+X     Cut
      • CTRL+C     Copy
      • CTRL+V     Paste
      • CTRL+A     Select All
      • CTRL+Z     Undo

    5. Click the note's Minimize button to close it and revert to Pan mode.

    6. To move the placement of a note:
      • Click the Edit Annotation Select Annotation button
      • Double-click an annotation icon in the document to edit it with full WordQ support.
      • Click the note's Minimize button to close the note and revert to Pan Pan mode.
    Edit an existing note or annotation
    1. Click the Edit Annotation Select Annotation button.

    2. Double-click a note's icon in the document to edit it with full WordQ support.

    3. Click the note's Minimize button to close it and revert to Pan Pan mode.

    Highlighting and Marking Up a Document

    Highlight or mark up non-editable text
    1. Click the Highlight Highlight button.

    2. Drag across the desired text to highlight it.

    3. Highlighting continues for more text until you select another mode such as Pan Pan or Edit Annotation Select Annotation.

    4. Additional mark-up tools are available under the Tools menu that work like the Highlight tool. These include Underline, Strikeout and Squiggly Underline.

    5. To change the color of marked up text:
      • Click on the highlighted or marked text while the Edit Annotation Select Annotation button is selected
      • Right-click on the marked text and choose Properties from the pop-up menu
      • Make your modifications in the pop-up dialog
    Draw on the PDF
    1. From the Tools > Draw > submenu, choose Line, Arrow, Oval, Rectangle or Ink.

    2. Drag across the document to draw the object.

    3. After each drawing, you will revert to Edit Annotation Select Annotation mode.

    4. To move or resize the drawn object:
      • Click on the object while the Edit Annotation Select Annotation button is selected
      • Drag the object to a new location
      • Drag one of the corners to resize

    5. To change the color of an object:
      • Click on the object while the Edit Annotation Select Annotation button is selected
      • Right-click on the selected object and choose Properties from the pop-up menu
      • Make your modifications in the pop-up dialog
    Add a note to highlighted or marked text, or a drawn object
    1. Click the Edit Annotation Select Annotation button

    2. Double-click on the highlighted/marked text, or drawn object.
      A pop-up note box will be displayed.
      Begin typing your note with full WordQ support.

    3. Click the note's Minimize button to close it and revert to Pan Pan mode.

    Viewing and Navigating Pages

    Page Display
    1. Click on one of the following toolbar buttons to change how a page is displayed:
    2. Fit Page     Fit Page fits the page within the height of the window

      Fit Width     Fit Width fits the page across the width of the window

      Single Page     Single Page displays a single page at a time

      Facing Pages     Facing displays pages side-by-side

      Rotate Clockwise     Rotate Clockwise rotates the page clockwise

      Rotate Counterclockwise     Rotate Counterclockwise rotates the page counterclockwise


    3. From the toolbar at the bottom of the window, you can Zoom Out Zoom Outor Zoom In Zoom In or specify a specify zoom level.

    4. Alternately, you can select from the View menu:

      • Fit Page fits the page across the width of the window
      • Fit Width fits the page within the height of the window
      • Zoom In to magnify the view of the document
      • Zoom Out to shrink the view of the document
      • Rotate Clockwise to rotate the page clockwise
      • Rotate Counterclockwise to rotate the page counterclockwise
      • Page Display >
        • Single Page displays a single page at a time
        • Facing displays pages side-by-side
        • Facing Continuous displays pages side-by-side with continuous scrolling
        • Facing Cover displays pages side-by-side and the document has a cover page
        • Facing Continuous Cover displays pages side-by-side with continuous scrolling and the document has a cover page
    Navigate Pages
    1. Select from the Navigation menu to jump to:

      • Next Page
      • Previous Page
      • First Page
      • Last Page

    2. From the toolbar at the bottom of the window, you can jump to a specific page, or the First Page First Page, Previous Page Previous Page, Next Page Next Page or the Last Page Last Page.
    Left Navigation Panel
    1. Click the Show Left Navigation Panel Show Left Navigation Panel button to display it on the left-hand side.

    2. Click the Thumbnail Thumbnails tab to display all pages as thumbnails. Click on a Thumbnail to jump to that page.

    3. Click the Contents Contents tab to display the document's outline or Table of Contents if it is included in the document. Not all documents have an outline or Table of Contents.

    4. Click the Whole Document Search Whole Document SearchSearch tab to search for a word or phrase in the document. If found, a list below will show the results. Click on a result to jump to that page where the word or phrase will be highlighted.

    5. Click the Annotations Annotations to display all annotations, highlights, mark ups, and added drawing objects in a list. The page number, date and time will be shown for each annotation.

    6. Click the Hide Left Navigation Panel Hide Left Navigation Panel tab to close the sidebar.
